Shade Sail Design

Becoming a great shade sail designer doesn’t happen overnight - you have to walk before you can run.  First, learn the basic do’s and don’ts.  There is a reason we compiled this list and it’s not to stifle your creativity.  We put this list together so that you don’t make the same mistakes we made in the beginning.



After you have a few projects under your belt you can start to throw in some options.  Observe how they turned out, what your customer liked or didn’t like and before you know it you will be an expert.



You will also need to learn some form of visualization tool.  Most people in the U.S. are not familiar with shade sails.  To close the sale you will need to show them what the project will look like.  Learning one of these programs goes hand in hand with learning design.

Wholesale Shade

Design Options

Once you have the basics of shade sail design down, you can begin to get creative with your designs. The design options are endless!

Kiss Point

A kiss point is where two sails meet in the middle. This is a nice example of form following function. The reason for the kiss is to close the gap between two sails creating more shade.

Doing this creates a unique and unexpected interaction between the sails resulting in a look only found in shade sails.

Wholesale Shade

Custom Curve Percentage

You can specify a custom curve depth or percentage on one side of a sail. This comes into play when going around a spiral staircase or the corner of a building.

Measuring for a custom curve is treated like measuring for a hole. We need the regular outside dimensions, plus dimensions from the anchor points to the center of the custom curve.

Edge Style Combinations

You can choose your edge style from cable, webbing, lace-on, flat bar pocket, or A-rail. Each style has its own benefits and restrictions. Sometimes the perfect shade sail design is a combination of more than one edge style.

For example, you may have a roof edge where the typical shade sail curve will let in too much sun. The best design might be an A-rail along the roof edge so that the gap is completely covered and no sun gets through. Combine this with cable on the other 3 sides and you have a custom solution with the appearance of a shade sail and the function of an awning.

The key to a successful combination sail is the transition from one style to the next. This is usually a high-stress point and needs to be done correctly. Give us a call if you have questions on a combo design and we’ll be happy to walk you through it.

Wholesale Shade
Wholesale Shade

Graphics

Shade cloth does not easily accept normal graphics like silk screening. We can, however, sew different colors of shade cloth together to create basic logos or graphics.

We cut the graphics out of shade cloth on our plotter/cutter and then sew them on top of the shade sail. We then cut out the shade sail material on the bottom leaving a graphic that can be seen from above and below. The graphic can often be seen as a shadow cast on the ground on a sunny day.

Extension Cables

What do you do when you want your sail to end at a certain point, but the only attachment point location is several feet away?

Extension cables are the answer.

Examples of when to use Extension Cables:



  • When your connection point is through trees or other obstacles, and you don’t want to have the sail rub against the branches.

  • To reduce the size of the sail when trying to keep costs down. For example, rather than extending the sail all the way to the attachment point, install an extension cable, thus reducing the square footage of the sail while keeping the function nearly the same.

Wholesale Shade

Shared Posts

A single post can be used for 2 or more sails. Typically, one sail will attach at the top and another sail will attach lower on the post.


This saves on the cost of steel and concrete vs. using 2 different posts, but keep in mind that this single post will need to be stronger since it carries the forces of 2 sails.

Posts are not usually thought of as attractive, so limiting the number usually contributes to a better design.

T-Posts

T-Posts are used to spread out the attachment points using a single footing. Sometimes you want the sails to overlap rather than share a single attachment point.



If it doesn’t make sense to use 2 posts, you can often weld a crossbar onto the post creating 2 attachment points.



This can be a dramatic design element while also reducing costs.

Custom Posts

Don’t be afraid to get creative with the look of your posts.

Check out this example where the posts are made to match the cacti in the surrounding area.

Sometimes you can’t have posts installed where you want them. So, it’s time to improvise and get creative with custom posts!

Angled Posts

You always want a little bit of an angle to the posts so that they don’t appear to tip in. We recommend at least ½ a bubble on a level tipped out away from the center of the sail. You can take this post angle up a notch by angling out 10-15 degrees or more. This can dramatically change the appearance of a shade sail project.

Consider placing the attachment points several feet down from the top of the posts giving the project a grand scale attracting more attention.

Wholesale Shade
Wholesale Shade

Cross Cables

Cross cables span between 2 attachment points creating a floating attachment point for the sail. This is usually done when it is difficult to locate a post in line with the center of the sail. The forces on a cross cable are multiplied, requiring high strength attachment points.

The sail attaches to the cross cable using a shackle and cable clamps to maintain position. Keep in mind that the cross cable will always angle in towards the shade sail, it will not end up straight. You can approximate this deflection by pulling the cross cable in the direction of the sail using a ratchet strap. Tighten the ratchet strap to the same tension that you would tighten a sail and use those measurements to order the sail.

Roof Bracket

Typically, residential designs include a patio area just outside the back door. On a one-story house, this means placing the sail as close to the eave as possible. A roof bracket may be the best solution to providing a high attachment point.

This bracket is listed in the “hard” category due to the risk of causing roof leaks and damage to the house. Make sure when installing a roof bracket that you follow the instructions to the letter, take your time, and don’t get distracted.

Exposed Webbing

Webbing perimeter sails are very popular in Australia. These can be ordered with covered webbing or exposed webbing that is sewn on the underside of the sail.



By using contrasting colors, you can really make a sail pop. This is a useful way to put corporate colors into a sail project.

Hems Up or Hems Down

You have the option to choose hems up or hems down. It is mostly a matter of personal preference.



Some people like the clean look of hems up which hides the stitching on the top of the sail where it can’t be seen. Others like hems down so that there is no lip to catch and hold leaves or debris.

In this blue sail, you can see that Hems Up has the hems folded on the side facing towards the sky, so they are less visible from underneath.

Shade sail corners Corner attachments for shade sails Shade sail corner hardware Shade sail corner tensioning Securing shade sail corners Triangular shade sail corners Square shade sail corners Rectangle shade sail corners Right-angle shade sail corners Reinforced shade sail corners Shade sail corner brackets Shade sail corner posts Shade sail corner anchors Tensioning devices for shade sail corners Shade sail corner installation tips Shade sail corner design Adjustable shade sail corners Shade sail corner kits Shade sail corner aesthetics Shade sail corner maintenance Shade sail corner safety Shade sail corner materials Shade sail corner durability Shade sail corner reinforcement Custom shade sail corner solutions Shade sail corner covers Shade sail corner caps Shade sail corner alignment Shade sail corner angles Shade sail corner support Shade sail corner specifications Shade sail corner standards Shade sail corner engineering Shade sail corner components Shade sail corner options Shade sail corner solutions for sun protection Shade sail corner solutions for rain protection Shade sail corner solutions for outdoor dining Shade sail corner solutions for event spaces Shade sail corner solutions for schools Shade sail corner solutions for parks Shade sail corner solutions for sports facilities Shade sail corner solutions for playgrounds Shade sail corner solutions for restaurants Shade sail corner solutions for hotels Shade sail corner solutions for cafes Shade sail corner solutions for public spaces Shade sail corner solutions for branding Shade sail corner solutions for marketing
Alnet shade sails Alnet shade sail fabric Alnet shade sail material Alnet shade sail features Alnet shade sail benefits Alnet shade sail installation Alnet shade sail design UV-resistant Alnet shade sails Alnet shade sails for sun protection Alnet shade sails for rain protection Alnet shade sails for outdoor dining Alnet shade sails for schools Alnet shade sails for parks Alnet shade sails for sports facilities Alnet shade sails for playgrounds Alnet shade sails for restaurants Alnet shade sails for hotels Alnet shade sails for cafes Alnet shade sails for public spaces Alnet shade sails for branding Alnet shade sails for marketing Alnet shade sail installation process Alnet shade sail maintenance Alnet shade sail cleaning Alnet shade sail care Alnet shade sail durability Alnet shade sail pricing Custom Alnet shade sail solutions Alnet shade sail project examples Shade sail with Alnet fabric High-quality Alnet shade sails Alnet shade sail reviews Shade sail with Alnet material

Light Side Up or Down

Some fabrics have a different appearance on the top vs. the bottom.



GALE Pacific has a two-toned fabric called DualShade with different complementary colors on top and on the bottom!

For Alnet fabrics, the top is the smooth, lighter colored side and the bottom is the rough, darker colored side.



Some customers prefer to see the lighter side while under the sail. In this case, you would specify “Light side down” on the order form. You can also customize the sail even further by specifying “Light Side down” and “Hems down” which will highlight the edge of the sail when viewed from underneath.

Visualization Tools

How do you show your customer what the project will look like?


My very first design was a cardboard box that I cut out and hot glued scraps of fabric for the sails.  The next phase was welding pieces of steel to the top of my welding table, again hot gluing scraps of fabric for the sail.  I would take photos from different angles to show the customer what it would look like.

Thankfully, times have changed and there are several options to create designs on your computer.

Design Do's and Don'ts

  • Policies
    All custom shade sail orders must: Complete & Sign the Order Form before the order is considered PLACED. Per our policy we ask for a 50% deposit upon ordering and the remaining balance plus shipping costs upon shipment. ​ Packages will not be released until final payment has been received. All packages are shipped via FedEx where tracking will be provided via email.
  • Lead Time
    Wholesale Shade offers 2 options for delivery, standard & 3 day. ​ Our standard lead time for custom products is 10 business days. ​ For 3 day service you are able to receive an order with a 3-day * some restrictions apply
  • Returns
    **Custom shade products are non-refundable no matter the circumstance unless authorized by Wholesale Shade. ​ If authorized, expect to receive a refund within two weeks from the date the item was shipped back to our facilities, however, in many cases the refund will be released quicker. This time period includes the transit time for us to receive your return from the shipper (5 to 10 business days), the time it takes us to process your return once we receive it (1 to 3 business days), and the time it takes the bank to process our refund request (5 to 10 business days).
  • Shipping
    Products are shipped via UPS or FedEx ground with signature required to ensure safe arrival. In removing the signature requirement per customer's request the customer agrees to assume all responsibility if the package is lost or stolen. Note: we do not ship to international destinations. Estimated shipping cost is not available until the product is packaged and ready to ship. Shipping rates for many items are weight-based. The weight of any such item can be found on its detail page. To reflect the policies of the shipping companies we use, all weights will be rounded up to the next full pound.

Visualization tools are an important part of the shade sail design process. Getting your customer to see your vision (and making sure that it matches theirs) is crucial to having a happy customer at the end of the day.



There are many options available to you, including several from MPanel, SketchUp, and Awning Composer. In this section, we cover some of the best options out there today, so that you can choose what works best for you.

Shade sail SketchUp Creating shade sail models in SketchUp SketchUp for shade sail design SketchUp 3D modeling for shade sails Shade sail design software SketchUp tutorials for shade sails SketchUp shade sail templates 3D modeling of shade sail structures SketchUp for shade sail planning Shade sail visualization with SketchUp SketchUp shading solutions Shade sail concept modeling in SketchUp SketchUp rendering for shade sail projects SketchUp plugins for shade sails SketchUp components for shade sail design Creating custom shade sail designs in SketchUp SketchUp for DIY shade sail projects Shade sail engineering with SketchUp SketchUp and shade sail layout Importing SketchUp models into CAD software Shade sail installation planning with SketchUp SketchUp 3D warehouse for shade sails Exporting SketchUp designs for fabrication SketchUp design process for shade sails Creating shade sail sketches with SketchUp Adding details to shade sail models in SketchUp Sharing SketchUp shade sail designs Collaborative design with SketchUp SketchUp rendering for client presentations SketchUp design for shade sail installations SketchUp tips and tricks for shade sail modeling
MPanel Insite Tensile membrane patterning software Shade sail design with MPanel Insite Tensile structure patterning solutions MPanel Insite features MPanel Insite benefits MPanel Insite tutorials MPanel Insite user guide Tensile structure modeling with MPanel Insite MPanel Insite for shade sail design Creating shade sail patterns with MPanel Insite Tensile structure analysis with MPanel Insite MPanel Insite software tools MPanel Insite for fabric patterning Tensile structure design and analysis MPanel Insite for architectural shading MPanel Insite for tensioned fabric structures MPanel Insite for sun protection design MPanel Insite for rain protection design MPanel Insite design process Tensile membrane engineering with MPanel Insite MPanel Insite support and updates MPanel Insite for shade structure professionals MPanel Insite case studies MPanel Insite pricing Custom shade sail design with MPanel Insite MPanel Insite for shading solutions Tensile fabric analysis and modeling MPanel

MPanel InSite (Interactive Site Designer) is a world’s first shade sail design tool that provides your sales team the ability to design sails in real-time, directly on the site, in 3D, and all in just minutes.

Import a .PDF or top-down image background which shows the site that you need to design sails for – this could be from an architect’s drawing, a satellite view or drone image of the site.

After setting up the site background you simply add poles, walls, and sails where you need cover. You can freely move poles around or change their heights to fine tune the design – the sails automatically stay connected to the poles.

Turn shadows on and off and adjust for any day, time, and geographic location to show the client that the sails not only look good but also do the job they're intended to do; provide shade.

Automatically generate printable reports and build specifications for the poles, all on custom looking reports complete with your company’s name and logo.



Learn more about MPanel InSite here: https://mpanel.com/products/mpanel-insite/


You can also watch InSite tutorials and find out more about MPanel InSite on their YouTube channel at:  https://www.youtube.com/watch?v=fS2JEmx7eFc

MPanel Shade Designer Shade structure design with MPanel MPanel Shade Designer software Tensile fabric design using MPanel MPanel for shade sail design Tensile structure modeling with MPanel Shade design software MPanel Shade Designer features MPanel Shade Designer benefits MPanel Shade Designer tutorials Creating shade structure designs with MPanel Tensile membrane engineering with MPanel MPanel Shade Designer user guide MPanel Shade Designer for sun protection MPanel Shade Designer for rain protection MPanel Shade Designer for outdoor shading Shade sail patterning with MPanel MPanel Shade Designer for architectural shading Tensile structure analysis with MPanel MPanel Shade Designer support and updates MPanel Shade Designer pricing Custom shade structure design with MPanel MPanel Shade Designer for shading professionals MPanel Shade Designer case studies Tensile fabric analysis and modeling MPanel Shade Designer for 3D design MPanel Shade Designer for tensile structure visualization

MPanel Shade Designer provides a step-by-step wizard interface that virtually walks the user through the process of creating a three-dimensional model and an accurate flat fabric pattern of a shade sail structure.

Utilizing the same powerful tools found in the popular MPanel Pro design and pattering software, MPanel Shade Designer features options for including seam allowance and material compensation (to plan for the stretch in the material) as well as a fully dimensioned pattern in a printable, production ready report, all with just a few clicks of the mouse.

Support for the user to create and save custom databases of different shade cloth materials and various corner hardware & connection methods are also included.



Learn more about MPanel Shade Designer here: https://mpanel.com/products/mpanel-shade-designer/



You can also watch Shade Designer tutorials and find out more about MPanel Shade Designer on their YouTube channel at:

https://www.youtube.com/watch?v=1CGFe9p5pxc&list=PLlFQftmRED8vTFU01XcvMzOGieBj-IGWJ

MPanel Shade Designer provides a step-by-step wizard interface that virtually walks the user through the process of creating a three-dimensional model and an accurate flat fabric pattern of a shade sail structure.  Utilizing the same powerful tools found in our popular MPanel design and pattering software, MPanel Shade Designer features options for including seam allowance and material compensation (to plan for the stretch in the material) as well as a fully dimensioned pattern in a printable, production ready report, all with just a few clicks of the mouse.

MPanel MPCALC is a simple to use web-based application for any smart-phone, tablet or PC with an Internet browser.  It provides a mobile platform that allows a user to enter connection point measurements and dimensions directly from the site and then check them for accuracy before you leave the project location.  If a measurement error is detected, you’ll know right away allowing you to find and correct it before you leave the site. If everything is accurate, you can simply enter your email address and have all of that collected data sent instantly back to your computer where it can be opened with MPanel Shade Designer.  No more re-typing in hand-written numbers off the back of a napkin; instead they are automatically entered into the correct form locations as soon as the file is opened in MPanel Shade Designer.


Learn more about the MPanel MPCALC application here: https://mpanel.com/products

SketchUp
SketchUp

SketchUp is useful from the earliest stages of design to the end of construction. Programming, diagramming, design development, detailing, documentation, RFIs—wherever you need drawings, you need SketchUp.

https://www.sketchup.com

Awning Composer
Wholesale Shade

Awning Composer includes several example shade sail models and also features seamless integration with MPanel Shade Designer, a separate application that lets you design shade sails based on site measurements and other parameters.

You can launch MPanel Shade Designer from Awning Composer and have the created 3D model automatically loaded into Awning Composer.

https://awningcomposer.com/pages/shadesail
